5-5.5" Bolt Circle 3,500 lbs. TruRyde® Trailer Axle Self-Adjusting Electric Brake Kit - BK555ELEAUTO-IPS

Pair of 10" hub/drum 5 studs 5.5" bolt circle using L68149 inner and L44649 outer bearing. Contains inner bearings, outer bearings, grease seals, grease caps, ultra lube grease caps, spindle washers, spindle nuts, cotter pins, tang washers, and lug nuts. (84 Spindle)

Pair of 10" x 2.25" self-adjusting electric trailer brake assemblies with parts. 4 Hole Mounting. For Alko, Dexter, Quality, or other popular trailer axle manufacturers. Only works on 3,500 lbs. trailer axles with four-hole brake flange. Includes mounting hardware. These are fully assembled backing plates with shoes, springs, and magnets attached and ready to be mounted. The pair includes one left hand and one right hand brake assembly.

Part No	Quantity	Description
RVD-U-555	2	TruRyde® 5-5.5" 10" Hub and Drum
BK-10E-01SA	1	TruRyde® 10"x2.25" Left Hand Self-Adjusting Electric Brake
BK-10E-02SA	1	TruRyde® 10"x2.25" Right Hand Self-Adjusting Electric Brake
716LW	8	7/16" Lock Washer
716NFN	8	7/16" Fine Hex Nut
DC-198	2	1.98" Dust Cap
FS622P	2	1.98" Lube Dust Cap with Rubber Plug
TW100	2	1" Tang Washer
A1W	2	1" Spindle Washer
FA-SN100	2	1"-14 Spindle Nut
18X134CP	2	Cotter Pin
L68149	2	TruRyde® Inner Bearing
L44649	2	TruRyde® Outer Bearing
GS-1719DL	2	1.719" ID Double Lip Grease Seal
X1023R	10	1/2"-20 Lug Nut 60 Degree 13/16" WAF
